3D CNC Basket Wire Forming Machine

3D CNC Basket Wire Forming Machine

Production description :3D CNC Basket Wire Forming Machine is to produce kinds of wire forms expertly with high precision and fast speed. Adopts Japanese Sanyo Denki servo motor and screen display with Taiwan controller.

Product Details

3D CNC Basket Wire Forming Machine


Production description :CNC 3D wire bending machine is to produce kinds of wire forms expertly with high precision and fast speed. Adopts Japanese Sanyo Denki servo motor and screen display with Taiwan controller.


Advantages & Features:

1.3-4 pairs feeding roller , feeding motor fixed on the bottom base, so as to decrease the feeding box weight, that wire rotating is more fast and light , turning angle is more precise and stable.

2.Twisting head is designed in copper tube transport, more stable and stronger than bearing transfer.


Technical Paramter:

Model

GT-WB-60-10A

GT-WB-80-9A

GT-WB-100-9A

GT-WB-120-7A

Wire size(mm)

2.0-6.0

3.0-8.0

4.0-10.0

5.0-12.0

axis

10

9

7

7

feeding roller number

3 pairs

3 pairs

4 pairs

4 pairs

wire turning angle

unlimited

unlimited

unlimited

unlimited

platform lifting height

20-100mm

25-120mm

25-120mm

25-120mm

twisting head lift height

50-170mm

25-180mm

25-180mm

25-180mm

distance between cutting is and bending head

/

210mm

      305mm

   105-405mm

distance between bending head and machine body

/

700mm

900mm

400-900mm

out twisting lifting height

20-55mm

/

/

/

left to right moving range

Left:80mm     Right:40mm

/

/

/

Feeding front and back moving range

Front:300mm    Back:300mm

/

/

/

axis

10

9

7

7

machine size(mm)

3000x1200x1400

3500x1200x1500

3800x1200x1500

3800x1200x1700

machine weight(kg)

3200

3500

4000

4800

Product display






Shipping and after-sale service
