Factory Direct Sale Special Hanger Hook Making Machine

Name: China Factory Direct Sale Special Hanger Hook Making Machine Manufacturers, Suppliers, Factory - Customized Service - Xinsheng Machinery
Brand: Xinsheng
SKU: 161383745

Mechanical hook making machine is to produce kinds of hooks expertly. There are 3 types for option. Hanger hook, tomato hook, and Eye screw hooks. It is with high output and stable quality. Once machine can achieve fully automatic in line, from feeding , straightening ,cutting, bending ,threading without stop. Labor saving and stable production. In case that threading teeth was very deep and pitch is big . must choose EH60-M.

Send Inquiry

Chat Now

Product Introduction

Dongguan Xinsheng Hardward Machinery Co., Ltd. is one of the moat reliable manufacturers and suppliers of factory direct sale special hanger hook making machine in China. If you're going to buy bulk cheap equipment, welcome to get pricelist and quotation from our factory. All customized machines are with high quality and low price.

Mechanical hook making machine is to produce kinds of hooks expertly. There are 3 types for option. Hanger hook, tomato hook, and Eye screw hooks.

It is with high output and stable quality. Once machine can achieve fully automatic in line, from feeding , straightening ,cutting, bending ,threading without stop. Labor saving and stable production.

In case that threading teeth was very deep and pitch is big . must choose EH6-M.

Technical Parameter:

Model 型号	GT-HM5	GT-EH5	GT-EH6-M	GT-EH8-M
Name品名	Ordinary hanger hook machine 普通衣架钩机	Eyelet hook machine 羊眼圈机	Oversize hanger hook machine 加大型衣架钩机	Heavy hanger hook machine 加重型衣架钩机
Wire size 线径	Iron :2.0-4.5mm Stainless steel 不锈钢1.5-3.5mm	Iron :2.0-5.0mm Stainless steel 不锈钢1.5-3.5mm	Iron：2.0-6.0mm Stainless steel 不锈钢1.5-4.0mm	Iron：3.0-8.0mm Stainless steel 不锈钢3.0-6.0mm
Feeding length长度	0-300mm	0-300mm	0-300mm	0-300mm
搓牙长度范围Threading length	15mm	30mm	100mm	100mm
生产速度Production rate	60pcs	60pcs	40pcs	18-20pcs
Forming motor 成型电机功率	2.2kw	2.2kw	3.75kw	5.5kw
搓牙电机功率Threading motor	1.5kw	2.2kw	3.75kw	5.5kw
Dimensions (LxWxH)尺寸	176x130x175CM	176x138x175CM	193x150x185CM	210x160x185CM
Weight重量	1000kg	1000kg	1100kg	1200kg
