CNC Coiling Spring Forming Machine
Dongguan Xinsheng Hardward Machinery Co., Ltd. is one of the moat reliable manufacturers and suppliers of cnc coiling spring forming machine in China. If you're going to buy bulk cheap equipment, welcome to get pricelist and quotation from our factory. All customized machines are with high quality and low price.
CNC spring coiling machine is to produce compression springs expertly with high precision and fast speed. Adopts Japanese Sanyo Denki servo motor and screen display with high quality controller.
Technical Parameter
Model | GT-CS-208 | GT-CS-220 | GT-CS-335 | GT-CS-550 | GT-CS-580 |
Wire size(mm) | 0.2-1.0 | 0.5-2.0 | 0.8-3.5 | 2.0-5.0 | 3.0-8.0 |
Max. outer dia. | 20mm | 50mm | 50mm | 60mm | 50mm |
Axes | 2 | 2 | 3 | 5 | 5 |
Feeding length | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited |
Wire feed speed | 0.-100M/min | 0-110M/min | 0-120M/min | 0-120M/min | 0-120M/min |
Production rate | 0-500pcs/min | 0-300pcs/min | 0-130pcs/min | 0-150pcs/min | 0-100pcs/min |
Wire feed Servo Motor | 1.0kw | 2.7kw | 5.5kw | 15.0kw | 30.0kw |
Cam Servo motor | 1.0kw | 2.7kw | 5.5kw | 4.5kw | 7.0kw |
Pitch(Quill)motor | / | / | 1.0kw | 2.7kw | 2.7kw |
Top cut motor | / | / | / | 4.5kw | 7.0kw |
Bottom cut motor | / | / | / | 4.5kw | 7.0kw |
Packing Size(L*W*H) | 1390X1030X1630 | 1490x1030x1700 | 1500x920x1700 | 1500x1300x1900 | 2200x1700x2400 |
Weight | 350.0kg | 800.0kg | 1200.0kg | 3500.0kg | 7500.0kg |
