3D Toys Wire Forming Machine
Dongguan Xinsheng Hardward Machinery Co., Ltd. is one of the moat reliable manufacturers and suppliers of 3d toys wire forming machine in China. If you're going to buy bulk cheap equipment, welcome to get pricelist and quotation from our factory. All customized machines are with high quality and low price.
3D Toys Wire Forming Machine
Product Application
This machine is designed to have no cam and without swing arm, which shorten the installation time and labour cost. less skill will be enough for tough task. keeping the advantage of traditional forming machine. excellent servo motors and reducers ensures excellent movement and precision of forming.
Model型号 | GT20-10 | GT25-10 | GT30-12R | GT35-10 | GT35-12R | GT45-12R | GT50-12R | GT60-12R | GT80-12R | GT100-12R | GT120-12R |
Wire dia(mm) | 0.2-2.0 | 0.2-2.5 | 0.4-3.0 | 0.8-3.5 | 0.8-3.5 | 1.2-4.5 | 1.2-5.0 | 2.0-6.0 | 3.0-8.0 | 4.0-10.0 | 5.0-12.0 |
Max. wire feeding value (mm) | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 | 10000 |
Min. wire feeding value (mm) | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
Max. wire feeding speed (m/min) | 120 | 120 | 120 | 120 | 80 | 80 | 80 | 80 | 80 | 60 | 60 |
Max. wire feeding length | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited | Unlimited 无限 |
Axis number | 10 | 10 | 12 | 10 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
Total output power of servo motors(kw) | 6.6KW | 10.0KW | 13.3KW | 14.2KW | 17.6KW | 21.8KW | 22.9KW | 39.8KW | 55.0KW | 86.3KW | 96.6KW |
Input power supply (V/HZ/PH) | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 | 380/50/3 |
Control system | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan | Made in Taiwan |
Program storage (plus) | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 |
Compressor air pressure (kg/cm) | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 | 5-6 |
Probe number | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 | 3 |
Overall length(mm) | 1100 | 1200 | 1500 | 1400 | 2200 | 2650 | 2650 | 3500 | 3500 | 4200 | 4300 |
Overall width(mm) | 800 | 1250 | 1250 | 1550 | 1550 | 1800 | 1800 | 2150 | 2150 | 2350 | 2500 |
Overall height(mm) | 1550 | 1760 | 1860 | 1800 | 1850 | 2070 | 2070 | 2150 | 2150 | 2580 | 2650 |
Net weight(kg) | 700 | 980 | 1500 | 1600 | 2500 | 4100 | 4500 | 7000 | 7200 | 12000 | 15000 |
Main Features
2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and closing.
4) Running in a high automatization and intellectualization,no pollution
5) Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .
