CNC Hook Bending Machine

Name: China CNC Hook Bending Machine Manufacturers, Suppliers, Factory - Customized Service - Xinsheng Machinery
Brand: Xinsheng
SKU: 208914148

CNC wire bending machine is to produce kinds of 2D and 3D wire forms expertly with high precision and fast speed. Adopts Japanese branded servo motor and screen display with high quality controller. Easy operation and fast turn-key.

Send Inquiry

Chat Now

Product Introduction

Dongguan Xinsheng Hardward Machinery Co., Ltd. is one of the moat reliable manufacturers and suppliers of cnc hook bending machine in China. If you're going to buy bulk cheap equipment, welcome to get pricelist and quotation from our factory. All customized machines are with high quality and low price.

CNC wire bending machine is to produce kinds of 2D and 3D wire forms expertly with high precision and fast speed.

Adopts Japanese branded servo motor and screen display with high quality controller. Easy operation and fast turn-key.

1. Advantages & Feature:

3-4 pairs feeding roller , feeding motor fixed on the bottom base, so as to decrease the feeding box weight, that wire rotating is more fast and light , turning angle is more precise and stable.

2. Application field:

1）Auto Industry area

2）Metal wire industry

3）Display table and cargo shelf

4）Furniture and Kitchen

5）Hardware industry

6）Mattress,Sofa spring area

7）Architecture area

8）Hardware Artcraft

3. Technical Paramter

Model	GT-WB-100-9A	GT-WB-80-8A	GT-WB-70-10A	GT-WB-70-8A	GT-WB-70-7A
Wire size	4.0-10.0mm	4.0-9.0mm	2.0-7.0mm	2.0-7.0mm	2.0-7.0mm
Axis	9	8	10	8	7
wire feeding value(mm)	Max.10000.00 Min.0.01	Max.10000.00 Min.0.01	Max.10000.00 Min.0.01	Max.10000.00 Min.0.01	Max.10000.00 Min.0.01
Feeding length number	3pairs	3pairs	3 pairs	3pairs	3 pairs
Wire turning angle	Unlimited	Unlimited	Unlimited	Unlimited	Unlimited
Platform Lifting Height	+25-120mm	+25-120mm	+25-120mm	+25-120mm	+25-120mm
twisting head lift height	+20-180mm	+20-180mm	+20-180mm	+20-180mm	+20-180mm
left to right moving range	Left:100mm Right:50mm	Left:100mm Right:50mm	Left:100mm Right:50mm	Left:100mm Right:50mm	Left:100mm Right:50mm
Feeding front and back moving range	Front:300mm Back:100mm	/	Front:300mm Back:100mm	/	/
Total output power of servo motors	27.8KW	25.8KW	24.2KW	17.5	16.2KW
Automatic decoiler	1000KG	800KG	500KG	500KG	500KG
machine size(cm)	420x152x160	420x152x160	380x1520x1600	260x122x160	250x122x160
machine weight	4500.0(kg)	4200.0(kg)	3800.0(kg)	3200.0(kg)	2800(kg)
